Models
EMG2 is an electro-magnetic 2-finger parallel gripper that is equipped with symmetrically actuated parallel jaws.
Advantages
- Compact size design with two installation positions for flexible mounting
- Grip actuation via an external control box
- Quick open/close actuation time
- Optional open/close position feedback provided by external proximity sensors
- Weight
- 0.20 kg0.44 lb
- Stroke Per Jaw
- 2 mm0.079 in
- Recommended Workpiece Weight
- 0.05 kg0.11 lb
- Working Temperature
- 0 - 40 °C32 - 104 °F
- Gripping Force per Jaw
- 3.5 - 5 N0.79 - 1.12 lb
- Total Gripping Force
- 7 - 10 N1.57 - 2.25 lb
- Opening/Closing Time
- 0.03 / 0.03 s
- Nominal Voltage
- 24 V DC ± 10%
- Nominal Current
- 0.1 A
- Max Current
- 2.5 A
- Number of Fingers
- 2
- Repeatability (Positioning)
- ±0.01 mm±0.0004 in
