Models
Flexibelt is a pneumatic robotic belt grinding tool with pendulous (swinging) compliance for adaptive contact during deburring/finishing operations.
Advantages
- Float-compensation system absorbs path deviations to maintain consistent tool engagement.
- Robotic-mounted design for integration in automated cells.
- Compatible with the full Amtru/Effecto tool changer ecosystem.
- Available in multiple sizes/power ratings to match application requirements.
- Designed for long service life in industrial deburring/grinding environments.
Electric - Radial Compliance
- Weight
- 300.00 kg661.39 lb
- Power
- 2.2 kW
- Compliance force @ 6 bar
- 17 N to 120 N3.8 to 27.0 lbf
- Rated Speed
- 1420 rpm
- Max. Compliance Movement
- 40 mm1.57 in
- Belt Rated Speed
- 22.3 m/s
- Power Supply
- 4 x 400 V / 50 Hz
- Belt Length
- 4 m13.1 ft
- Max. Belt Width
- 100 (optional 125) mm3.94 (optional 4.92) in
- Max. Belt Tension Force
- 483 N108.6 lbf
- Rotation Device
- 2 x 90°
