Models
Eccocut is a milling and sawing deburring tool designed for robotic edge finishing of metal workpieces.
Advantages
- Combined milling and sawing capability for versatile edge work.
- Robotic-mounted design for integration in automated cells.
- Compatible with the Effecto/Amtru tool changer ecosystem.
- Designed for long service life in industrial deburring environments.
Electric - No compliance
- Weight
- 60.00 kg132.28 lb
- Power
- 3.0 kW
- Idling Speed
- 9200 rpm
- Maximal Speed
- 12000 rpm
- Rated Torque
- 3.2 Nm28.3 in-lb
Electric - No compliance
- Weight
- 60.00 kg132.28 lb
- Power
- 3.0 kW
- Idling Speed
- 5800 rpm
- Maximal Speed
- 9000 rpm
- Rated Torque
- 5.0 Nm44.3 in-lb
Electric - No compliance
- Weight
- 69.00 kg152.12 lb
- Power
- 5.5 kW
- Idling Speed
- 9200 rpm
- Maximal Speed
- 12000 rpm
- Rated Torque
- 5.7 Nm50.4 in-lb
Electric - No compliance
- Weight
- 69.00 kg152.12 lb
- Power
- 5.5 kW
- Idling Speed
- 5800 rpm
- Maximal Speed
- 9000 rpm
- Rated Torque
- 9.1 Nm80.5 in-lb
Electric - No compliance
- Weight
- 69.00 kg152.12 lb
- Power
- 5.5 kW
- Idling Speed
- 3870 rpm
- Maximal Speed
- 6000 rpm
- Rated Torque
- 13.6 Nm120.4 in-lb
Electric - No compliance
- Weight
- 69.00 kg152.12 lb
- Power
- 5.5 kW
- Idling Speed
- 2900 rpm
- Maximal Speed
- 4500 rpm
- Rated Torque
- 18.1 Nm160.2 in-lb
Electric - No compliance
- Weight
- 69.00 kg152.12 lb
- Power
- 5.5 kW
- Idling Speed
- 1450 rpm
- Maximal Speed
- 2500 rpm
- Rated Torque
- 36.2 Nm320.4 in-lb
