Models
Flextapper is a pneumatic robotic thread cutting/tapping tool with axial compliance for adaptive contact during deburring/finishing operations.
Advantages
- Float-compensation system absorbs path deviations to maintain consistent tool engagement.
- Robotic-mounted design for integration in automated cells.
- Compatible with the full Amtru/Effecto tool changer ecosystem.
- Available in multiple sizes/power ratings to match application requirements.
- Designed for long service life in industrial deburring/grinding environments.
Pneumatic - Axial compliance
- Weight
- 4.20 kg9.26 lb
- Power
- 230 W
- Idling Speed
- 840 rpm
- Compliance force @ 6 bar
- approx. 60 Napprox. 13.5 lbf
- Fluid Consumption
- 7.8 l/s16.5 cfm
- Rated Speed
- 435 rpm
- Compliance Movement
- 12 mm (axial)0.47 in (axial)
- Tool Insertion Mounting
- for M5
- Thread size in aluminum
- ≤M8 (Ref. value)
- Thread size in Steel
- ≤M6 (Ref. value)
Pneumatic - Axial compliance
- Weight
- 4.40 kg9.70 lb
- Power
- 230 W
- Idling Speed
- 385 rpm
- Compliance force @ 6 bar
- approx. 60 Napprox. 13.5 lbf
- Fluid Consumption
- 7.8 l/s16.5 cfm
- Rated Speed
- 190 rpm
- Compliance Movement
- 12 mm (axial)0.47 in (axial)
- Tool Insertion Mounting
- Collet ESX12 Ø 2-7 mm
- Thread size in aluminum
- ≤M10 (Ref. value)
- Thread size in Steel
- ≤M8 (Ref. value)
